Surpass Hobby Waterproof 45A Brushless ESC
Surpass Hobby Waterproof 45A Brushless ESC
Couldn't load pickup availability
- FREE Shipping for Orders over $29!
- Dispatch Within 1 Business Day!
- 30-Day Change of Mind Returns!
Waterproof and Dustproof Design:
Built for all-weather racing, this ESC is engineered to withstand harsh conditions, allowing you to race in wet, muddy, or dusty environments with confidence.
Optimized for RC Cars:
Experience exceptional start-up, acceleration, and linearity with this ESC, designed specifically for sensorless brushless motors in RC cars.
High-Performance Capabilities:
With strong current resistance and excellent heat dissipation, this ESC ensures reliable performance even during the most demanding races.
Multiple Protection Features:
Equipped with advanced safety measures, including low voltage cut-off protection for lithium and nickel batteries, over-heat protection, throttle signal loss protection, and motor block protection, this ESC guarantees a safe and durable operation.
Easy Programming:
Compatible with a pocket-sized program card, making adjustments quick and easy for both novice and experienced RC enthusiasts.
Specifications:
- Brand: Surpass Hobby
- Model: KK Series 45A ESC
- Continuous/Burst Current: 45A / 240A
- Motor Type: Sensorless Brushless Motor
- Resistance: 0.0014 ohm
- BEC Output: 5.8V / 3A (switch mode)
- Battery Compatibility: 2-3S LiPo / 4-9 NiMH cells
- Car Compatibility: 1/10 scale cars
- Dimensions / Weight: 51.5x38.5x38.5mm / 76g
- Connector: Deans / T plug
Motor Recommendations:
- For 2S LiPo or 6-Cell NiMH:
- On-Road: 3656 size or smaller motors with KV <5600KV
- Off-Road/Buggy/Monster: 3660 size or smaller motors with KV<3800KV
- For 3S LiPo or 9-Cell NiMH:
- On-Road: 3660 size or smaller motors with KV < 3800KV
- Off-Road/Buggy/Monster: 3660 size or smaller motors with KV < 2600KV
This waterproof ESC combines performance, durability, and safety, making it an ideal choice for RC enthusiasts looking to push their vehicles to the limit.
