HobbyWing Skywalker V2 120A ESC - 10A BEC
HobbyWing Skywalker V2 120A ESC - 10A BEC
Couldn't load pickup availability
- FREE Shipping for Orders over $29!
- Dispatch Within 1 Business Day!
- 30-Day Change of Mind Returns!
Unlock the full potential of your RC aircraft with the HobbyWing Skywalker 120A V2 Brushless ESC. Specially engineered for air applications, this ESC integrates cutting-edge technology and robust protection features to deliver outstanding performance and efficiency. Whether you're a seasoned pilot or just starting out, the Skywalker 120A V2 is the ideal upgrade to enhance your flying experience.
Key Features:
32-Bit Microprocessor: Powered by a high-performance 32-bit ARM M4 master chip running at 120MHz, this ESC is capable of handling up to 300,000 RPM for a 2-pole motor. It offers explosive power and rapid response, making it suitable for 60-67" 3D fixed-wing aircraft.
DEO Technology: The Driving Efficiency Optimization (DEO) technology dramatically improves throttle response, driving efficiency, and reduces ESC temperature, ensuring smoother and more efficient flights.
Reverse Brake Modes: The ESC includes Reverse Brake and Linear Reverse Brake modes, which can effectively shorten the landing distance of your aircraft, simulating the landing behavior of a real aircraft. Normal Brake Mode and Brake Disabled Mode are also available, with adjustable brake amounts in Normal Brake Mode.
Search Mode: If your aircraft lands in a visually obstructed area, the Search Mode pulses the motor to beep, helping you locate it. This mode can also remind users to disconnect the battery from an idle ESC, preventing the battery from being drained and damaged.
Multiple Protection Features: The Skywalker ESC is equipped with multiple safety features, including protection against abnormal input voltage, ESC thermal overload, throttle signal loss (Fail Safe), and low voltage cutoff. These features ensure the longevity and reliability of your ESC.
Separate Programming Cable: Customize your ESC settings anytime, anywhere by connecting it to an optional LED program box (sold separately). This feature allows for easy programming to meet your specific flying needs.
Specifications:
- Model: 120A V2
- Input Voltage: 3-8S LiPo
- BEC Output: Switch Mode - 5V/6V/7.4V/8.4V, 10A/30A
- Continuous Current: 120A
- Peak Current: 150A
- Dimensions: 83x35x22mm (LxWxH)
- Weight: 117g
- Input Wire: 10AWG-150mm
- Output Wire: 12AWG-100mm
- Output Connectors: 4.0mm Bullets (Female)
Package Includes:
- 1x HobbyWing Skywalker V2 120A ESC
- 1x User Manual
Elevate your flying experience with the HobbyWing Skywalker 120A V2 Brushless ESC—designed for unmatched reliability, performance, and efficiency in every flight. Perfect for pilots seeking superior control and enhanced protection for their RC aircraft.
